Epoxy Glass Resin Fiber Glass FR-4 Sheets

Fiber glass epoxy FR4 sheet is a NEMA grade designation for glass-reinforced epoxy laminate material. Fiber glass epoxy FR4 sheet is a composite material composed of woven fiberglass cloth with an epoxy resin binder that is flame resistant (self-extinguishing). "FR" stands for flame retardant, and denotes that the material complies with the standard UL94V-0. FR4 sheet is a popular and versatile high-pressure thermal plastic laminate grade with good strength to weight ratios. With near zero water absorption, fiber glass epoxy sheet is most commonly used as an electrical insulator possessing considerable mechanical strength. The material is known to retain its high mechanical values and electrical insulating qualities in both dry and humid conditions. These attributes, along with good fabrication characteristics, lend utility to this grade for a wide variety of electrical and mechanical applications.

Product Description

Specifications:
High temperature resistance, High intensity, Flame-retardant grades to UL94-V0, High mechanical properties and Dielectric properties, Good heat resistance, Good-smoothness,etc.
FR-4 epoxy material is accordance with the following international standards:IEC60893 EPGC202
NEMA LI-1:FR4/DIN 7735 HGW 2372.1/BS 3953 EP-4

1)Thickness:0.1mm-100mm
2)Size: 1030x1230mm, 1030*1030mm
3)Payment terms: T/T or L/C at sight
4)Package: wooden pallet, Carton or according to customer requirements

5)Delivery time:10-20 days
